Product Description
 |  |  | |
| Name | ZARN3585-L-TV | ZARN3585-L-TV | 3585R/3525 |
| Brand | INA (Schaeffler) | INA | NACHI |
| thrust directions: | Double-Direction | ||
| radial bearing outside diameter: | 60 mm 2.3622 in | ||
| operating temperature range: | -30 to +120 °C | ||
| fillet radius: | 0.6 mm 0.0236 in | ||
| radial dynamic load capacity: | 6180 lbf | ||
| cage material: | Plastic | ||
| radial static load capacity: | 11900 lbf | ||
| series: | ZARN | ||
| bore diameter: | 35 mm 1.378 in | ||
| axial dynamic load capacity: | 23600 lbf | ||
| outside diameter: | 85 mm 3.3465 in | ||
| axial static load capacity: | 60000 lbf | ||
| overall width: | 82 mm 3.2283 in | ||
| maximum rpm: | 4000 RPM | ||
| bearing type: | Needle Roller/Axial Cylindrical Roller | ||
| closure type: | Open |
