Product Description
 | |  | |
| Name | 22330UAVS2 | MX-22330UAVS2 | 6E-22330UAVS2 |
| Brand | NTN | NTN | NTN |
| bore diameter: | 150 mm 5.9055 in | ||
| operating temperature range: | -40 to 120 ºC | ||
| outside diameter: | 320 mm 12.5984 in | ||
| cage material: | Brass | ||
| overall width: | 108 mm 4.252 in | ||
| bearing material: | Through Hardened Steel | ||
| bore type: | Straight | ||
| cage type: | Machined | ||
| outer ring type: | Not Split | ||
| precision rating: | Not Rated | ||
| internal clearance: | Upper 2/3 of C4 range | ||
| finish/coating: | Uncoated | ||
| closure type: | Open | ||
| outer ring width: | 108 mm 4.252 in | ||
| lubrication hole type: | Lubrication Groove & Hole | ||
| inner ring width: | 108 mm 4.252 in | ||
| dynamic load capacity: | 1240000 N | ||
| fillet radius: | 4 mm 0.1575 in | ||
| static load capacity: | 1320000 N | ||
| series: | 223 | ||
| maximum rpm: | 1300 rpm | ||
| manufacturer product page: | Click here | ||
| Size (mm) | 150x320x108(mm) | 150x320x108(mm) | |
| Bore Diameter (mm) | 150,000(mm) | 150,000(mm) | |
| Outer Diameter (mm) | 320,000(mm) | 320,000(mm) | |
| Width (mm) | 108,000(mm) | 108,000(mm) | |
| d | 150,000 mm 5.9055 in | 150,000 mm 5.9055 in | |
| D | 320,000 mm 12.5984 in | 320,000 mm 12.5984 in | |
| H | 108,000 mm 4.252 in | 108,000 mm 4.252 in | |
| Category | Spherical Roller Bearings | Bearings | Spherical Roller Bearings |
| BDI Inventory | 0.0 | 0.0 | 0.0 |
| Manufacturer Name | NTN | NTN | NTN |
| Minimum Buy Quantity | N/A | N/A | N/A |
| Weight / Kilogram | 43.55 | 48 | 43.55 |
| EAN | 4547359520217 | 0692314641484 | |
| Product Group - BDI | B04311 | M06288 | B04311 |
| Internal Clearance | C0-Medium | C0-Medium | |
| Mounting Method | Shaft Mount | Shaft Mount | |
| Rolling Element | Spherical Roller Bearing | Spherical Roller Bearing | |
| Bore Profile | Straight | Straight | |
| Cage Material | Bronze | Bronze | |
| Enclosure | Open | Open | |
| Number of Rows of Rollers | Double Row | Double Row | |
| Relubricatable | Yes | Yes | |
| Withdrawal Sleeve | Not Applicable | Not Applicable | |
| Withdrawal Nut | Not Applicable | Not Applicable | |
| Inch - Metric | Metric | Metric | |
| Long Description | 150MM Straight Bore; 320MM Outside Diameter; 108MM Width; C0-Medium Clearance; Shaft Mount; Double Row of Spherical Roller Bearings; Bronze Cage Material; Open Enclosure; Relubricatable | 150MM Straight Bore; 320MM Outside Diameter; 108MM Width; C0-Medium Clearance; Shaft Mount; Double Row of Spherical Roller Bearings; Bronze Cage Material; Open Enclosure; Relubricatable | |
| Category - BDI | Spherical Roller Bearing | Spherical Roller Bearing | |
| UNSPSC | 31171510 | 31171510 | |
| Harmonized Tariff Code | 84823080 | 84823080 | |
| Noun | Bearing | Bearing | |
| Keyword String | Spherical | Spherical | |
| Manufacturer URL | http://www.ntnamerica.com | http://www.ntnamerica.com | |
| Weight / LBS | 95.914 | 95.914 | |
| Outside Diameter | 12.598 Inch | 320 Millimeter | 12.598 Inch | 320 Millimeter | |
| Width | 4.252 Inch | 108 Millimeter | 4.252 Inch | 108 Millimeter | |
| Bore | 5.906 Inch | 150 Millimeter | 5.906 Inch | 150 Millimeter | |
| Adapter Part Number | Not Applicable Inch | Not Applicable Millimeter | Not Applicable Inch | Not Applicable Millimeter |
