Home>Products>Complex Bearings>NATB 5903 IKO Complex Bearings
English
-
Loyal Bearing Co.Ltd2020-07-10 09:46:19
Welcome to my shop! Glad to serve you! Please send your question!
Product Description
 |  |  | |
| Bearing number | NATB 5903 | NKIA5903A | NATA 5903 |
| Size (mm) | 17x30x20(mm) | 17x30x18(mm) | 17x30x18(mm) |
| Brand | IKO | NTN | IKO |
| Bore Diameter (mm) | 17(mm) | 17,000(mm) | 17(mm) |
| Outer Diameter (mm) | 30(mm) | 30,000(mm) | 30(mm) |
| Width (mm) | 20(mm) | 18,000(mm) | 18(mm) |
| d | 17 mm 0.6693 in | 17,000 mm 0.6693 in | 17 mm 0.6693 in |
| Fw | 22 mm 0.8661 in | 22 mm 0.8661 in | |
| D | 30 mm 1.1811 in | 30,000 mm 1.1811 in | 30 mm 1.1811 in |
| B | 20 mm 0.7874 in | 18,000 mm 0.7087 in | 18 mm 0.7087 in |
| C | 18 mm 0.7087 in | 18,000 mm 0.7087 in | 18 mm 0.7087 in |
| r min. | 0,3 mm 0.0118 in | 0,3 mm 0.0118 in | |
| da min. | 19 mm 0.748 in | 19 mm 0.748 in | |
| Da max. | 28 mm 1.1024 in | 28 mm 1.1024 in | |
| Weight | 0,0585 Kg | 0,0555 Kg | |
| Dynamic load rating radial (C) | 8,22 kN | 8,22 kN | |
| Dynamic load rating axial (C) | 2,05 kN | 2,05 kN | |
| Static load rating radial (C0) | 11,5 kN | 11,5 kN | |
| Static load rating axial (C0) | 3,34 kN | 3,34 kN |
Loyal Bearing Co., Ltd. has been highly praised by the industry for its high quality products, excellent service and timely supply capability. Loyal Bearing Co., Ltd. wholeheartedly welcomes domestic and foreign customers, peers to call or come to discuss cooperation to create a better future!
